Crystal Form
Alpha SiC hexagonal system
Chemical nature
Slight acid
Reaction with acids
Very slight surface action with hydrofluoric acid
Reaction with Alkalis
Attacked at high temperature by alkalis and iron oxide
Oxidation-reduction effects
Starts to oxide slowly at 800°C. No reduction
True Density (g/cm3)
3.20
Hardness
Knoop (kg/cm2)
2500-2900
Moh’s
9.5
Color
Green
Color after firing
Decomposition point
2300°C
Max Usable temperature
1540°C in air
Specific heat (cal/g.oC )
0°C
500°C
1000°C
0.14
0.28
0.13
Coefficient of thermal conductivity (cal/cm2.sec.oC)
600°C
800oC
0.080
0.061
0.051
Electrical resistivity(Wcm)
25°C
100°C
400°C
800°C
1400°C
50
46.4
26.6
7.8
0.65
Coefficient of liner expansion (x10-6)
25°C -500°C
25°C -1000°C
25°C-1500°C
25°C-2000°C
25°C-2500°C
4.63
5.12
5.48
5.77
5.94
Chemical Composition (% by weight) Grit sizes SiC F.C Fe2O3 20# - 90# 99.0 min 0.20 max 0.20 max 100# - 180# 98.5 min 0.25 max 0.50 max 220# - 240# 97.5 min 0.25 max 0.70 max 280# - 400# 97.0 min 0.30 max 0.70 max 500# - 600# 95.5 min 0.30 max 0.70 max 800# - 1200# 94.0 min 0.30 max 0.70 max
Grit sizes
SiC
F.C
Fe2O3
20# - 90#
99.0 min
0.20 max
100# - 180#
98.5 min
0.25 max
0.50 max
220# - 240#
97.5 min
0.70 max
280# - 400#
97.0 min
0.30 max
500# - 600#
95.5 min
800# - 1200#
94.0 min
Grit
Magnetic material Content
16#-30#
<0.018
36#-60#
<0.015
70#-120#
<0.012
150#-220#
<0.010
Grinding wheels
Heating elements
Coated tools
Refractory
Polishing
Electrical
Lapping
Ceramic
Available Sizes: F10-F220, F230-1200, W63-W5, JIS240-JIS3000. Other sizes can be also available according to customers' requirements.
Packing way: 25kgs/bag or by customer's request.
